Switches, Cables and Connectors

PCB for MPX 8-pin high current connector

Package: 1 piece

High quality double-sided PCB for MPX 8-pin connector. For soldering of servo extension cables and their mechanical securing.

Use for quick wing assembly or attach to the fuselage for quick servo connection with the wings in radio controlled (RC) airplanes, helicopters, cars, trucks, buggies, boats and other models. It can be used together with the MPX 8-pin connector (1M71285).

MPX 8-pin high current connector

Package: 1 pair

High quality MPX 8-pin connector with gold-plated solder contacts.

Current rating:

• 6A / 24h
• 8A / 5min
• 10A / 3s

Use for quick wing assembly or attach to the fuselage for quick servo connection with the wings in radio controlled (RC) airplanes, helicopters, cars, trucks, buggies, boats and other models. It can be used together with solder board for easy wiring (8GR71294-1).

Muldental Elektronik Highly flexible 0,50 mm2 silicone power cable with red electrical insulation.

Stranded wire from 270 strands 0.05 mm
Outer diameter: 1.5 mm
Max voltage: 48 V
Continuous current load: 7.5A
Peak current (5min): 20.5A

Made in Germany

Muldental Elektronik Highly flexible 0,50 mm2 silicone power cable with black electrical insulation.

Stranded wire from 270 strands 0.05 mm
Outer diameter: 1.5 mm
Max voltage: 48 V
Continuous current load: 7.5A
Peak current (5min): 20.5A

Made in Germany

Muldental Elektronik Highly flexible 1,00 mm2 silicone power cable with red electrical insulation.

Stranded wire from 516 strands 0.05 mm
Outer diameter: 2.3 mm
Max voltage: 48 V
Continuous current load: 18.2A
Peak current (5min): 31.3A

Made in Germany

Muldental Elektronik Highly flexible 0,50 mm2 silicone power cable with black electrical insulation.

Stranded wire from 516 strands 0.05 mm
Outer diameter: 2.3 mm
Max voltage: 48 V
Continuous current load: 18.2A
Peak current (5min): 31.3A

Made in Germany

Muldental Elektronik Highly flexible 4.00 mm2 silicone power cable with red electrical insulation.

Stranded wire from 1020 strands 0.07 mm
Outer diameter: 4.2 mm
Max voltage: 48 V
Continuous current load: 42.5A
Peak current (5min): 73.2A

Made in Germany

Muldental Elektronik Highly flexible 4.00 mm2 silicone power cable with black electrical insulation.

Stranded wire from 1020 strands 0.07 mm
Outer diameter: 4.2 mm
Max voltage: 48 V
Continuous current load: 42.5A
Peak current (5min): 73.2A

Made in Germany

Muldental Elektronik Highly flexible 6.00 mm2 silicone power cable with red electrical insulation.

Stranded wire from 1561 strands 0.07 mm
Outer diameter: 4.8 mm
Max voltage: 48 V
Continuous current load: 54.5A
Peak current (5min): 95.3A

Made in Germany

Muldental Elektronik Highly flexible 6.00 mm2 silicone power cable with black electrical insulation.

Stranded wire from 1561 strands 0.07 mm
Outer diameter: 4.8 mm
Max voltage: 48 V
Continuous current load: 54.5A
Peak current (5min): 95.3

Made in Germany

Glow Clip Charging Cable with 4mm banana connectors

Graupner ON/OFF Switch with leads

Graupner Quick Attach/Detach Wing Connector Kit

MPX MPX 6-pin connectors (5 pairs)

Heat Shrink Tube 3mm

Red and black
Length: 25cm each

Heat Shrink Tube 4mm

Red and black
Length: 25cm each

Heat Shrink Tube 6mm

Red and black
Length: 25cm each

Graupner Servo Lead Extension (cable) 200mm

With JR connector (0.3mm2 cable)

Muldental Elektronik Highly flexible 6.00 mm2 silicone power cable with red electrical insulation.

Stranded wire from 1260 strands 0.1 mm
Outer diameter: 6.5 mm
Max voltage: 48 V
Continuous current load: 73A
Peak current (5min): 126A

Made in Germany

Muldental Elektronik Highly flexible 6.00 mm2 silicone power cable with black electrical insulation.

Stranded wire from 1260 strands 0.1 mm
Outer diameter: 6.5 mm
Max voltage: 48 V
Continuous current load: 73A
Peak current (5min): 126A

Made in Germany

Twisted Servo Extension Cable (300mm)

Twisted Extension cable with JR connectors (0.25mm2). The connector is fitted with a snap-on clip to secure the connector inside.

Konect Maxi On/Off Switch with (XT60/JR/Graupner cable)

The Ming Yang Heavy Duty ON/OFF Switch Harness (JR/Graupner cable)

Flat Y-lead servo extension cable (150mm)

Flat Y-cable cable with JR connectors

Charging Adapter Cable for Futaba/BEC/Glow (igniter) with Deans (T-plug) connector

SkyRC XT60 Charging Cable for 2S Lipo Battery (4mm and 5mm)

4 and 5mm gold connectors

SkyRC Dual Charging (Port) Balancer Board with XH adapter

Specification:
Cell: 2-8S LiPo
Connector: XT60 for battery / XH balance ports
Fuse: 2x 40A

High current gold-plated connector G6 mm

Packing: female (2 pcs)

Tamiya Plug Silver (female)

Gold-plated connector G8.0mm with segmented elastic pin with max. load 170A (long-term 80A)

For cables up to 13.3 mm2 (6 AWG)
Transition resistance 0.15 mOhm, max. 500 V

Packing: 1 pair
